数据中心的发展趋势

栏目:综合技术时间:2015-03-26 09:43:24

数据中心的发展趋势

Per Brasher

       描绘某些个别公司热中于对之夸大其词的趋势实在是太受人欢迎了。我的公司Yttibrium(Per Brasher是该公司的开创人,同时也是PMC的资深技术顾问)耗费了数周的时间,寻根究底,试图为客户描画出1幅清晰的图画 。以下是针对今后几年数据中心发展趋势的若干核心预测。

寻求电能使用效力(PUE)最小化的时期1去不复返

       由于美国能源署严格规定,任何取得国家科学基金的项目必须保持PUE在1.4乃至更高水平,而ASHRAE (美国采暖、制冷与空调工程师学会TC9.条令则建议城市PUE值保持在1.2或更高,几近所有的建筑公司要末是找到了切实方法,要末是把数据“洗绿”了以满足这些需求。如果你还不了解该计算程式的漏洞所在,只需想想,若是在系统中加上效力显著提升的IT负载会怎样样…哦?!明显,发明这个方程的目的并不是意在中断IT负载层面的任何创新?!

转向机架级别的解决方案

       愈来愈多的机架在远址构建,1旦运至数据中心,只需“分分钟”就能够设置好。许多厂商都将其吹嘘成软件定义的数据中心(SDDC),但实际上,远址集成、常规测试、稳定性老化测试等所节省的本钱开支非常客观。企业还没有积极地拥抱这1软件定义的理念,主要缘由是本钱/风险的计算还不太明确。但机架级的解决方案在本钱和风险两方面的优势均10分显著。因此,可以预计,待解决方案供应商们醒过劲儿后,对机架级产品的需求将大幅度爬升。

基于POD的设计

       我避免称其为“模块化”或“容器化”的设计,缘由在于有些解决方案利用了空置的仓库,在中间摆放1个容载系统;另外一些则成排构建,在后门或走道旁放上散热片;还有些公司则把全部建筑拿来使用。数据中心系统的建设正趋向于:消除过去巨大的前期1次性的基础设施的建设投资,随着自己业务增长而逐渐购买、扩建数据中心装备。从基础设施的角度来看,任何部件都可以预先设计,再在部署时进行按需复制。一样地,下降风险与本钱自然有其优势,因此,预计这个领域也会有快速的增长。

低能耗密度的解决方案是王道

       随着经济实用成了惯常的考量标准,而提供的方案的温度却延续提升,散热能力就成了管理中的重要因素。DCiM工具与利用负载的集成尚有欠缺,尚不理想,因此,就有赖于从密度的角度来下降能耗。由于多数时候,访问速度并不是相当重要,所以将会看到数据中心的建筑从城市中心区域向郊区转移的趋势,从而减缓了采用50+U的机架或高密度计算的压力。

气流方面的优化对全球60%可用地点均行之有效

        选择干燥温暖的地方还是温暖湿润的地方?这是个辣手的问题。但是除用水这1块的节能装置的额外开消,还需要巨大的储水罐来昼夜下降水温,这些都会增加整体本钱,而对风险控制并没有补益。根据其设计说明,所有IT装备(除磁带之外)都可适用于两种系统。另外,也有云和COLO供应商在力图获得额外的本钱节俭(既能下降构建本钱,也能减少运营本钱)。

SAS将会成为经常使用的存储网络

       连接在SAS“网格”上的SATA终端愈来愈常见。其技术挑战在于,当为SATA建立隧道传送数据时,不同速率的端点(磁盘)会阻碍其它端点的通讯。因此我们把这些看成微型网络,可支持多种简化/局限的利用场景:例如保护倒换来实现高可靠性,或简单的同享和提高可靠性的机制。事实证明,将硬盘从服务器机架上取出并置于独立的外壳内确有其好处(下降了EMI,从而延长了其使用寿命),一样也改良了其服务效力(速度更快,无需工具便可进行替换),但是却缺少任何网络智能。

值得关注的技术趋势

       HDD-> SMR

       DRAM-> NVDiMM

       IA-> SOC

       Tape-> BluRay

       NVMe/ PCIE Gen4 得到强势推动



 Data Center Trends

       It was incredibly popular to write abouttrends that one or another company thought reasonable to self aggrandize about.Yttibrium spent literally weeks sifting through all the mud to get a clearpicture for our clients. Here is our top pick for the coming year(s).

The Race for a Low PUE is Over

       With the DOE having mandated anyonegetting NSF funds must have a PUE of 1.4 or better, and ASHRAE TC9.9 havingmade the recommendation that municipalities require a PUE of 1.2 or better(good option to get more revenue if you ask me..tax the wasters!) Almost everybuilder out there has either created anoffering, or found a way to 'green wash' the numbers to meet the needs. If youare not familiar with the faultiness of the formula, just think what happens tothe overall number when you put in significantly more efficient IT load.. oops,that is not the intention of the formula, to stop innovation at the IT loadlevel.

Move to Rack Scale Solutions

       Racks are more and more being builtoff-site and once rolled into the DC, provisioned in 'minutes'. Many vendorstout this as SDDC, but in reality the cost savings of off-site integrators,test and burn in before the equipment hist the floor is compelling. Enterpriseshave been slow to adopt much of the SD* due mostly to an unclear cost/riskcalculation, but with Rack Scale Solutions having both lower cost and lowerrisk, expect to see the demand rise significantly as solutions providers wakeup.

POD Based Designs

        I avoid calling them 'Modular' or'Containerized' because some solutions use empty warehouse spaces, and plop acontainment system in the middle, and others build a row, put cooling fins onthe rear doors or over the isle, and even some build the whole building likethis. Point being the trend to sale as you grow Data Center systems haseliminated the huge up-front costs we saw in the past. Now everything from theinfrastructure point of view can be predesigned, and copy-paste deployment style.Again lowered risk, and lowered cost has it effect, so expect to see rapidadoption in this space as well.

Low Power Density Solutions Dominate

        As economizers are becoming the norm,and the supply side temperatures are being raised, the ability to cool becomesa critical element to manage. DCiM tools are not up-to-snuff yet, with a lackof integration with app loads, so we look to the density question to reducerisk. Since most access speeds are not critically important, look to see thebuildings trend away from the metropolitan districts in favor of a suburbanspace. this releases the pressure to go to 50+ U racks and high densitycompute, after all, "land is cheap outside Boise ID".

Airside Economizers Work for 60% of Potential Sites World Wide

       The choice of warm and dry vs. warm andwet is a real battle, but with the added losses of the waterside economizer,huge storage tanks are needed to cool the water over night, and use it duringthe day. That makes the overall cost rise, but does little to reduce risk.

SAS will Become the Storage Network

       SATA endpoints on a SAS 'fabric' isbecoming more popular. Challenge is when tunneling SATA, endpoints of differingspeeds, can bugger up things for the others. So we see these as micro nets,allowing a very reduced use-case, like HA fail-over, or other simpleavailability/sharing needs. The trend to take the drives off of the serverchassis and into their own enclosure has proven better for the drives (loweredEMI etc. makes them live longer) and for service (faster and tool-less swap),but left us wanting for just a little touch of network intelligence.

Technologies to Watch

       HDD-> SMR

       DRAM-> NVDiMM

       IA-> SOC

      Tape-> BluRay

      NVMe/ PCIE Gen4 getting a needed shot of steroids

      Sensors in the DC, BigData will start to run the DC
